Taylor Mk2 660L 4 Wheel Metal Bin is a popular-sized container; the Mk2 660L has a deceptively large capacity in a small footprint. Its slim configuration allows it to fit through a standard doorway, making it ideal for indoor storage or secure collection areas.

Taylor Mk2 660L: 660 Litre Trade Bin, Galvanised Steel Shell, Internally seams welded. The comb lifting bar is manufactured from 2.0mm** thick galvanised steel and features 7 gussets for additional strength. DuraFlex Trade Lid: Manufactured from high-grade UV-stabilised polyethylene. With Standard Flat Trade Lid, Taylor 200mm Steel Centred castors, 2x Back / Rear swivel Castors, 2 x Foot operated braked castors, Danish Side Handles for easy Manoeuvrability in confined bin storage areas

Standard Build: 660 Litres Galvanised. Steel General Waste Bin With Danish Side Handles Internally Welded Seams, Welded On Comb Bar, EN840 compliant, Internally seam welded Hot dip galvanised body Welded comb bar, X 4 160mm Steel Centred Bolt On Castors For Easy Replacement, X 2 Foot Operated Standard Side Braked Castors X 2 Swivel Rear Castors Fitted with Black Duraflex Back Trade Lid, Lock and Base Drain Plug. Prices from: £352.00 Excluding VAT.(12 Month Warranty) Delivery Time 2-4  Working Weeks

Standard Build Options and Bin Finishes:
X 4 200mm Steel Centred Bolt On Castors For Easy Replacement, X 2 Foot Operated Braked Castors X 2 Swivel Rear Castors Options: Side loading DIN points, Powder coated body 12 colour options (See Colour Chart )
4 Lid types & apertures,  Duraflex Black Trade Lid, High Dome 2 Aperture Bottle Recycling Lid, High dome Recycling Flap Lid,:   Drain plug varieties Standard Lid Drain Plug, (Rodent Replant Drain Plug) Powder coated body colour options (See Colour Chart), Standard vinyl graphics. Custom embossing Hinged Drop Front suitable for Materials Storage. Hinged Drop Back suitable for General Waste.



Image Mk2 660 Trade Bin For Guild Line Purposes
Galvanised Steel Shell
Seam Welded Internally
Height 1340mm
Depth 720mm
Width 1270mm
S.W.L 264Kg
Danish Side Handles
Welded Comb Bar
Standard Drain Plug
X4 Steel Centred 160mm Castors
2 Rear Swivel Castors: 2  Front Foot Operated Locking Castors
3 Duraflex Lid Options
See Drawing At the Bottom Of the Page

Mk2 660L Recycling Bin Specification and Build Finish Options

• 660L Galvanised Steel Body, hot-dipped galvanised steel along with fully internally welded seams, ensures robust protection in the harshest of environments and protects the container from internal corrosion due to residual waste being caught in exposed corners.
• The container can be powder-coated option using polyester powder, which is baked and cured in a controlled oven process, providing a layer of protection against corrosion, scratches/chipping and fading, being one of the longest-lasting, superior paint finishes, and colour-durable quality available in 12 standard colours
• The Comb Bar is manufactured from a single piece of steel with welded end pieces and gussets.
• The top frame is a complete welded tube, not split or open-bend, with a diameter of 20mm. The use of the complete welded tube is very important here, as by using a complete tube, there are no holes or gaps in which waste can leak into the top frame itself when the container is lifted on emptying
• Container Bin Lids are Rotary-moulded double-skin plastic with a minimum weight of 5.0 kilo, manufactured in an aluminium mould for a superior finish with 12 Standard Colour Options.
• Container Bin Lid Options
• Standard Trade Lid
• 2 Aperture Bottle Brush Lid
• Recycling Flap Lid
• Bolt-on Castor Options for easy replacement
• Standard 200mm Steel Centred Castors
• Heavy Duty 200m Castors
• 200mm High-Speed Towing Castors
• None Marking 200mm Castors

All four castors are 160mm steel-centred rubber-tyred swivel castors, two of which are fitted with trailing brakes (Brakes are pressed to lock, pressed to release)

All four castors are 200mm steel-centred wheels manufactured with needle bearings, grease, and rubber optimised for performance steel-centred rubber-tyred swivel castors, two of which are fitted with trailing brakes (Brakes are press to lock, press to release) and are bolted on for easy replacement. Two-foot operated, trailing braking wheels at the front with two swivel wheels at the back. (Not Welded On or Plastic Centred Castors)

Also available with Castors Options
Heavy Duty 20mm Casters: Mainly used with bins fitted with a heavy-duty base, suitable for dense waste materials (Food Waste) and also for loading waste compactors and bins fitted with External and Internal fork pockets.

Non-marking casters are mainly used by Airports and Hotel lobbies, Schools, Hospitals, Offices, and Shopping Centres, which have non-marking floor Vinyl, Epoxy, and Laminate Floor covering.

Continental Towing containers are fully adapted and built with a heavy-duty reinforced base, heavy-duty Power castors and a removable tow link system allowing up to 4 wheeled containers to be moved at a time, subject to bin size and materials, ground conditions, and material weights
Heavy Duty Power Towing Castors  2 Swivel 2 Directional Lock is designed for towing up to 4 bins and also comes standard with a heavy-duty base, including a bolt-on towing hitch and eye.

Bin Towing Containers provide a safe, practical answer to all towing requirements. Any container that is to be towed should be fitted with heavy-duty Power Towing castors or two swivel castors complete with directional locks, at one end of the container, and no more than 4 containers are towed at any one time.

Please contact us on 01709 730341 if you need more information on “Towing Guidelines” or Castor Options and technical advice.

Available with either a Drop Front or Drop-Back Panel


Mk3 660 Drop Front Storage Container have been created to help avoid the health and safety risks associated with handballing bagged or bulky waste, often an essential requirement within retail and manufacturing environments or easy emptying, mainly used by businesses with limited access.

Standard Build: 660 Litre 4 Wheel Galvanised Metal Hinged Drop Front Panel Storage Container : Fitted with Duraflex Black Trade Lid and Lid Lock- X 4 160 mm Bolt on Steel Centred Castors For Easy Replacement, 2 Front Braked Foot Operated Brake Locking Castors,2 Rear Swivel Castors. Not fitted with Comb Lifting Bar, Base Drain Plug:  Prices From £559.00 Plus V.A.T. (12 Months Warranty)

Taylor, 4 Wheel Metal Bins. Taylor 660L is fully EN840 compliant. The powder-coated body means it has higher resistance against scuffs, scratches, corrosion and colour discolouration/fading.

Available In 12 Standard Colours

Different Lid Types & Apertures Suitable for recyclingLids are rotary-moulded double-skin plastic with a minimum weight of 5.0 kilos, manufactured in an aluminium mould for a superior finish.

Standard Trade Lid
The innovative rotary moulded, double-skinned lid is waterproof and extra strong. The lid lock plug can be removed for easy post-fitting of a lid lock.
Suitable for Trade waste, General waste, Black bag waste and. None recyclable materials

Dimensions Duraflex Taylor - MA4927 Trade Waste 4 Wheel Bin Container lid Flat lid to fit Taylor 660 litre bins .L: 673mm x W: 1 233mm x  H: 81mm With: 7 Ribs For Optimal Strength

Available in a range of 12 colour options

Bespoke Logos Can Be Applied To Any Bin, showing what can be correctly recycled
Effective use of a logo alongside an eye-catching paint scheme is a key aspect in the design of your bins and can convey a powerful brand image or message regarding
Container Bin use. Personalise your containers with a complete range of Wrap logos or by adding bespoke logos.

Mk2 660L  Trade Bin: Please Phone DJE At 01709-730341 Or Via the Contact Form

Dimensions Taylor Mk2 660L Bin Standard Build

660L Build Variants and Similar Size Bins Images are Linked, Showing Bin Dimensions

Bin Compliance:

• Double tank method as dictated by European Standard BS EN 840
• Quality Control Certification to BS EN ISO 9001:2000
• Bin comply in full with European Standard BS EN 840
• Certification to Environmental Standard BS EN ISO 14001
• Recycling bins comply in full with ‘The Noise and Emission in the Environment by Equipment for Use Outdoors Regulation 2001’. BSENISO3744:1985
• Hot-dip galvanised to meet BS EN 1461: 2009
• Body steel, all joints fully welded, with all internal body seams continuously welded. All steel parts are galvanised after manufacture to meet BS 729.
• Galvanised steel body with internal fully welded seams
